Cub Cadet Yanmar Sx3100 User Manual

Sx Series
Sx3100
Copyright 2010 Cub Cadet Yanmar LLC
REF
NO.
PART NUMBER DESCRIPTION QTY
2 CY-158553-51090 Key,Woodruff 3X10 1
3 CY-158553-61050 Packing, Case 1
4 CY-158553-61070 Packing 1
6 CY-129155-51280 O-Ring S6 1
22 CY-129255-61410 Nut 1
23 CY-119807-61420 Spring 1
24 CY-119852-61440 Lever, Regulator 1
25 CY-129155-61460 Bolt, Idle Limit 1
59 CY-119660-61901 Retainer, Shaft 1
63 CY-22190-120000 Seal Washer 12(Bolt) 1
65 CY-23887-120002 Plug M12,Hex. 1
67 CY-26106-060102 Bolt 6X 10 Plated 1
68 CY-26756-060002 Lock Nut 6 1
77 CY-158552-61900 O-Ring 1
83 CY-26106-060142 Bolt M 6X 14 Plated 2
84 CY-26106-060142 Bolt M 6X 14 Plated 4
85 CY-26106-060202 Bolt M 6X 20 Plated 10
86 CY-158552-61061 Cover, Case 1
87 CY-119852-61080 Support,Acc.Wire 1
93 CY-129155-61590 Nut 1
130 CY-119653-77950 Solenoid, Stop 1
131 CY-26106-060142 Bolt M 6X 14 Plated 2
27
FIG. 13. GOVERNOR
