Cub Cadet Yanmar Sx3100 User Manual

Sx Series
Sx3100
Copyright 2010 Cub Cadet Yanmar LLC
REF
NO.
PART NUMBER DESCRIPTION QTY
1 CY-729008-53100 Fuel Injector(Sdl 3
2 CY-129008-53000 Nozzle Assy 3
5 CY-114250-53080 Nut, Nozzle Case 3
6 CY-119802-53100 Holder Assy, Nozzle 3
10 CY-114250-53120 Spring, Nozzle 3
11 CY-114250-53130 Seat, Nozzle Spring 3
12 CY-114250-53140 Plate, Stop 3
13 CY-114250-53210 Pin 6
14 CY-119803-53400 Shim Set 3
41 CY-129232-50101 Stay,Feed Pump 1
42 CY-26106-080142 Bolt 8X 14 Plated 3
43 CY-129150-59120 Retainer, Inj. Pipe 2
46 CY-129150-59131 Bolt M4X14,Hex.Sckt. 4
48 CY-129004-59811 Pipe Assy, Injection 1
52 CY-129004-59821 Pipe Assy, Injection 1
56 CY-129004-59831 Pipe Assy, Injection 1
60 CY-129263-59550 Pipe Assy, Return 1
61 CY-129486-59320 Corrugated Tube 1
62 CY-119802-59550 Pipe Assy, Return 1
63 CY-124722-59050 Clamp 9 2
64 CY-119802-59560 Pipe, Fuel Return 1
65 CY-129486-59551 Pipe, Fuel Return 2
66 CY-124722-59050 Clamp 9 4
68 CY-119593-59581 Cap 1
69 CY-23080-010000 Clamp 10 1
29
FIG. 14. FUEL INJECTION VALVE
