Page #31 background image
Sx Series
Sx3100
Copyright 2010 Cub Cadet Yanmar LLC
REF
NO.
PART NUMBER DESCRIPTION QTY
1 CY-129407-77010 Starter Assy 1
2 CY-X0283060061 Roller 5
3 CY-X9490561370 Nut 1
4 CY-X9491200240 Ball 1
5 CY-124795-77210 Yoke 1
6 CY-129407-77220 Armature Assy 1
7 CY-129129-77230 Bearing 1
8 CY-129129-77240 Bearing 1
9 CY-129407-77250 Starter Kit 1
10 CY-X0280210230 Nut 1
11 CY-X0283270140 Retainer 1
12 CY-129407-77390 Clutch,Starter 1
13 CY-129129-77440 Bearing 1
14 CY-129129-77450 Bearing 1
15 CY-129129-77400 Shaft 1
16 CY-129129-77410 Spring, Coil 1
17 CY-129407-77410 Spring 1
18 CY-129129-77420 Pinion 1
19 CY-129129-77430 Ring 1
20 CY-129129-77260 Retainer 1
21 CY-129129-77270 Pinion 1
22 CY-129407-77280 Housing 1
23 CY-129129-77290 Frame 1
24 CY-129407-77300 Holder Assy 1
25 CY-X9491730461 Spring 4
26 CY-129407-77310 Switch Assy 1
27 CY-129129-77320 Bolt 2
28 CY-129407-77330 Bolt,W/Washer 2
29 CY-129129-77340 Spring 1
30 CY-129129-77350 O-Ring 2
31 CY-129129-77362 Cover 1
33 CY-129129-77380 Cap 1
34 CY-129129-77460 Screw 2
35 CY-129155-77060 Bolt, Starter 1
36 CY-26116-120202 Bolt M12X 20 Plated 1
31
FIG. 15. STARTING MOTOR
