Page #36 background imageLoading...
Page #36 background image
Sx Series
Sx3100
Copyright 2010 Cub Cadet Yanmar LLC
REF
NO.
PART NUMBER DESCRIPTION QTY
1 CY-729232-01000 Short Block Assy 1
2 CY-129232-01560 Cylinder Block Cmp 1
3 CY-729402-01650 Case Assy, Oil Seal 1
4 CY-129150-14200 Tappet 6
5 CY-129129-14580 Camshaft Assy 1
6 CY-129008-21000 Crankshaft Assy 1
7 CY-129005-22080 Piston Assy 3
8 CY-129202-22300 Pin, Piston(D26,L70) 3
9 CY-729402-23100 Rod Assy, Connecting 3
10 CY-119802-25101 Gear Assy, Idle 1
11 CY-22252-000260 Circlip 26 6
12 CY-26106-080142 Bolt 8X 14 Plated 2
36
FIG. 19. SHORTBLOCK
