Cub Cadet Yanmar Sx3100 - Page 39

Sx Series
39
Sx3100
FIG. NO GROUP NAME
continued from page 38
83 HOOD
84 DASHBOARD
85 FENDER
86 STEP
87 SEAT BRACKET
88 DRIVER SEAT
89 LABEL 1
90 LABEL 2
91 LABEL, SAFETY
HITCH SECTION Pg 166-173
92 PTO GUARD
93 PTO SHAFT COVER
94 OIL SEAL COVER
95 THREE POINT HITCH
96
REAR HITCH
97 DRAW BAR HITCH
98 ROPS 1
99 ROPS 2
100 SMV
1 LABEL
2 LABEL SAFETY
3
SUPPORT FRAME
4
BRACKET
5 BOOM
6 QUICK LINK
7 CYLINDER
8 HYDRAULIC PIPING
9 PROTECTOR
10 STAND
11 BUCKET 53
12 BUCKET 61
TRACTOR SECTION INDEX
FITTINGS SECTION PG 148-165
SAFETY FRAME SECTION Pg 174-176
LOADER SECTION Pg 178-191
