Cub Cadet Yanmar Sx3100 User Manual

Sx Series
Sx3100
Copyright 2010 Cub Cadet Yanmar LLC
REF
NO.
PART NUMBER DESCRIPTION QTY
1 CY-1A7540-00510 Pipe Cmp, Ext 1
2 CY-1A7540-00600 Radiator Kit 1
3 CY-1A8300-00600 Shroud 1
4 CY-1A7530-00620 Protector 1
5 CY-1A7530-00690 Packin 4
6 CY-121250-44570 Pipe, 7X300 1
7 CY-119924-44580 Valve Assy,Drain 1
8 CY-129107-44590 Cap, Radiator D46 1
9 CY-26014-060202 Bolt M 6X 20 4
10 CY-26557-060122 Screw M 6X 12,Pan Hd 4
11 CY-1A7540-00630 Support Rod Cmp 1
12 CY-198162-00640 Support 2
13 CY-1A8300-00680 Pipe, Intake 1
14 CY-1A7540-00720 Cw-T (L 1
15 CY-1A7540-00730 Cw-T (U 1
16 CY-1A7530-00750 Stay,Subtank 1
17 CY-1A7540-04150 Bracket, Filter Cmp 1
18 CY-26018-080252 Bolt M8X 25 3
19 CY-26106-080302 Bolt M 8X 30 Plated 2
20 CY-129052-13550 Gasket 1
21 CY-194990-22050 Nut W/Washer 8 1
22 CY-129263-44510 Tank Assy, Sub 1
23 CY-121450-44531 Cap 1
24 CY-124450-44560 Clamp 1
25 CY-23065-070180 Pipe 7X 180 1
26 CY-121470-44581 Gasket 1
27 CY-121454-44590 Pad 1
28 CY-175022-49730 Crip 31, Hose 4
29 CY-129004-55612 Bracket, Filter 1
30 CY-119802-55801 Filter, Fuel 1
31 CY-198448-60780 Weather-Strip, 470 2
32 CY-198220-62440 Grommet 2
33 CY-172164-66620 Rubber, Seal 320 1
34 CY-198129-78710 Spacer, 6-10 4
35 CY-198129-78720 Grommet, 10-16 2
36 CY-22157-060000 Washer 6 4
37 CY-23010-060000 Clamp 60 1
38 CY-26018-060302 Bolt 6X30 4
39 CY-26018-080202 Bolt M 8X 20 2
43
FIG. 1. ENGINE ACCESSORIES
