Cub Cadet Yanmar Sx3100 - Page 57

Sx Series
Sx3100
Copyright 2010 Cub Cadet Yanmar LLC
REF
NO.
PART NUMBER DESCRIPTION QTY
1 CY-1A7531-11350 Bolt, M10X25 10
2 CY-1A7531137301 Case, Final Gear L.H 1
3 CY-1A7531137401 Case, Final Gear R.H 1
4 CY-194274-13550 Bolt M10X 30 4
5 CY-194274-13570 Spring Washer 10 8
6 CY-1A7531137101 Case, Front Gear 2
7 CY-198165-13750 Shim 2
8 CY-1A7510-13750 Support, King Pin L 1
9 CY-1A6780137601 Steering Arm R.H. 1
10 CY-194516-13770 Sleeve Si455016 2
11 CY-194516-13780 Seal Tc6Y 506812.5 2
12 CY-1A7531-13810 Pinion, Front Final 2
13 CY-198165-14120 Fainal Gear, Front 2
14 CY-1D4110-13870 Washer 2
15 CY-1A6780-13890 Ring 47 2
16 CY-198165-24440 Gasket(20*12*2 2
17 CY-198165-24490 Bolt M 12X 12 Plated 2
18 CY-194320-42150 Bolt M10X 35 4
19 CY-1E6190-54080 Sleeve Si25X30X13 2
20 CY-22312-080200 Parallel Pin, M8X20 4
21 CY-22312-100200 Parallel Pin, M10X20 2
22 CY-24101-060084 Ball Bearing 2
23 CY-24104-062044 Ball Bearing 2
24 CY-24421-304708 Seal Tc30 47 08, Oil 2
57
FIG. 13. FRONT GEAR CASE
