Cub Cadet Yanmar Sx3100 User Manual

Sx Series
Sx3100
Copyright 2010 Cub Cadet Yanmar LLC
REF
NO.
PART NUMBER DESCRIPTION QTY
1 CY-1A7530-17640 Pipe, High Press. Ps 1
2 CY-1A7540-17670 Pipe, Outlet Ps 1
3 CY-1A7540-17710 Pipe, Drain 1
4 CY-1A7530-17821 Hose,Hydraulic 2
5 CY-1A7530-17830 Hose, Hydraulic 2
6 CY-1A8300-17940 Hose, Oil Cooler 2
7 CY-194990-22050 Nut W/Washer 8 2
8 CY-1A7130-48110 Clamp, Pipe 1
9 CY-1E8600-66700 Cooler,Oil 1
10 CY-23000-019000 Clamp 19 4
11 CY-23414-160021 Gasket 16 4
12 CY-23857-100000 Joint Bolt 10 2
13 CY-24311-000120 O-Ring 1A P-12.0 4
14 CY-26018-080202 Bolt M 8X 20 4
15 CY-26018-080202 Bolt M 8X 20 1
69
FIG. 24. PST PIPING A
