Cub Cadet Yanmar Sx3100 User Manual

Sx Series
Sx3100
Copyright 2010 Cub Cadet Yanmar LLC
REF
NO.
PART NUMBER DESCRIPTION QTY
1 CY-1C6560-13170 Bearing 16005,Ball 2
2 CY-194640-25390 Ball Bearing 1
3 CY-194505-25600 D-Ring 80 1
4 CY-198167-26080 Collar Set,Spl Pto 1
5 CY-198165-26150 Spline Collar, Pto 1
6 CY-198167-26220 Collar, Shift 1
7 CY-1A7540-26160 Gear(Clutch 33T 1
8 CY-1A6680-26170 Gear 41T,Pto 1
9 CY-198165-26180 Joint 1
10 CY-1A7540-26180 Shaft Assy, Clutch 1
11 CY-1E6191-54330 Screw 7X8 1
12 CY-1A7530-26190 Gear, Pto Z=10T 1
13 CY-198165-26210 Brake 1
14 CY-1A7540-26210 Cylinder, Clutch 1
15 CY-198165-26240 Collar 15Xt2.5 1
16 CY-198167-26240 Ring, 21X25X3 Seal 2
17 CY-1A7540-26240 Key, 5X40 1
18 CY-198167-26250 Shaft,Pto Drive Out 1
19 CY-1A7540-26250 Piston, 80 1
20 CY-1A7540-26260 Washer, 36X48X2 1
21 CY-198165-26270 Bearing Tmb302 1
22 CY-1A7540-26310 Gear(Pto Idle Z=35 1
23 CY-1A7530-26330 Gear, Pto Idle Z=45 1
24 CY-198167-26340 Shaft, Idle Mid 1
25 CY-192159-31410 Bearing,6204R Sh2 1
26 CY-1E6190-54430 Thrust Washer (C) 2
27 CY-1E6740-54440 Plate 80,Friction 8
28 CY-1E6740-54450 Plate 1.2,Steel 8
29 CY-1E6710-54460 Spring,Clutch Return 1
30 CY-1E6330-54490 Plate 3.2, Steel 1
31 CY-22242-000200 Circlip 20 1
32 CY-22242-000250 Circlip 25S 1
33 CY-22242-000360 Circlip 36(S) 1
34 CY-22252-000180 Circlip 18 1
35 CY-22252-000470 Circlip 47(H) 1
36 CY-22252-000520 Circlip 52 1
37 CY-22252-000800 Circlip 80 1
38 CY-22551-050300 Key 5X30 1
39 CY-24101-060074 Ball Bearing 1
40 CY-24101-062044 Ball Bearing #6204 2
41 CY-24101-062054 Bearing #6205 1
42 CY-24101-063054 Bearing #6305 1
43 CY-24161-202417 Bearing 1
44 CY-24164-000202 Circlip 20-S 1
45 CY-26018-080352 Bolt M8X35 1
87
FIG. 38. PTO CLUTCH SHAFT

Cub Cadet Yanmar Sx3100 Specifications

General

Brand	Cub Cadet
Model	Yanmar Sx3100
Category	Tractor
Language	English
