1 CY-1A7530-27650 Stay Cmp, 4Wd Switch 1
2 CY-198167-28210 Gear,Drive Mfwd 1
3 CY-1A7540-28220 Gear, Idle Mfwd 1
4 CY-194311-28230 Spring 21.2 1
5 CY-198165-28240 Collar,Shift Front 1
6 CY-198167-28240 Gear,Driven Mfwd 1
7 CY-1A7530-28250 Shaft, Mfwd Drive 1
8 CY-1A7530-28270 Collar, 25.4X30X14.8 1
9 CY-1A7530-28280 Collar, 30X38X30.7 1
10 CY-1A7530-28290 Shaft, Front Drive 1
11 CY-198167-28310 Arm,Cmp Shift 4Wd 1
12 CY-198165-28330 Brock,Shift 1
13 CY-1A7540-28880 Bearing, 283516 1
14 CY-1E6190-54080 Sleeve Si25X30X13 1
15 CY-22242-000290 Circlip 29 2
16 CY-22252-000470 Circlip 47(H) 1
17 CY-22252-000550 Circlip 55 1
18 CY-24101-060054 Ball Bearing 6005 1
19 CY-24104-060064 Ball Bearing 2
20 CY-24190-080001 Ball 1/4, Steel 2
21 CY-24311-000125 O-Ring 1A P-12.5 1
22 CY-26016-080202 Bolt M 8X 20 1
95
FIG. 44. FRONT DRIVE
