Page #99 background imageLoading...
Page #99 background image
Sx Series
Sx3100
Copyright 2010 Cub Cadet Yanmar LLC
REF
NO.
PART NUMBER DESCRIPTION QTY
1 CY-1A7530-24450 Cover Assy, Side R 1
2 CY-1A7530-24470 Gasket, Side Cover R 1
3 CY-194180-25930 Washer 12X27X4.5 1
4 CY-1A7530-27510 Spring, Return 1
5 CY-1A7530-27520 Fulcrum, N Center 1
6 CY-1A7530-27550 Stay Cmp, Absorber 1
7 CY-1A7530-27570 Washer, 35X47X2 2
8 CY-192157-27600 Control Arm Comp. 1
9 CY-1A7530-28800 Plate, Swash 1
10 CY-1A7530-28850 Plate, Control Arm 1
11 CY-1E1270-29701 Support 1
12 CY-22137-120000 Washer 12,Polished 1
13 CY-22312-080160 Parallel Pin 8X 16 2
14 CY-24311-240100 O-Ring 1A P-10A 1
15 CY-24421-355008 Seal Tc35 50 08, Oil 1
16 CY-26016-080162 Bolt M 8X 16 1
17 CY-26016-080202 Bolt M 8X 20 1
18 CY-26016-080402 Bolt M 8X 40 9
19 CY-26016-120302 Bolt M12X 30 1
20 CY-26018-080252 Bolt M8X 25 1
21 CY-26716-080002 Nut M 8 1
22 CY-26776-120002 Lock Nut M12 Plated 1
99
FIG. 46. HST CONTROL 1
