CUMMINS ALLISON JetScan iFX i100 - Example No. 1: Ordered Recovery ON

© 2013 Cummins-Allison Corp.
107
Condition
Action
TRANSPORT JAM
(Continued)
The REPROCESSING; RETURN DOCUMENTS TO HOPPER screen will appear,
as shown below.
4. Place documents in the hopper, and the machine automatically will
continue processing.
How to Manually Remove Documents from the Transport Path:
1.
Lift display panel to the upright
position.
2.
Push release levers down to disengage
the upper-transport plate.
3.
Lift upper-transport plate to the locked
position.
4.
Remove jammed documents.
5.
Press down on the release levers to unlock the upper-transport plate
from the open position. Press down on the upper-transport plate until it
locks in the closed position.
6.
Lower display panel to the operating position.
