Curtis Instruments AC F4-A User Manual

7 — DIAGNOSTICS AND TROUBLESHOOTING
Curtis AC F4-A Motor Controller – August 2020 Return to TOC
pg. 180
Table 18 Fault Code Troubleshooting Chart, cont’d
FLASH
CODE
FAULT NAME
(Curtis Integrated Toolkit™)
POSSIBLE CAUSES SET/CLEAR CONDITIONS FAULT ACTIONS
10-9
0xA9
Coil Supply Fault
Coil_Supply_Fault_Active
0x2169
Fault Type(s):
1 = short to B- or HW fault.
2 = Coil Supply disabled due to
shorted (internal) driver*.
3 = Coil Supply startup enable
check failed.
4 = Coil Supply startup disable
check failed.
*a short must rst be detected.
1. Short on driver loads.
2. Dirty connector pins at controller
or device.
3. Bad connector crimps or faulty
wiring.
4. Controller is defective.
Set: Short detected after the
startup check has passed.
A low side driver short is
detected and the respective
fault action fails to cut-off
driver current.
Coil supply startup test fails.
Clear: Reset Controller.
ShutdownAll:
ShutdownMotor
ShutdownMainContactor
ShutdownEMBrake
ShutdownThrottle
ShutdownInterlock
ShutdownDriver1
ShutdownDriver2
ShutdownDriver3
ShutdownDriver4
ShutdownDriver5
ShutdownDriver6
ShutdownDriver7
ShutdownPD
FullBrake
ShutdownPump
ShutdownCoilSupply
ShutdownVehicle
ShutdownLower
ShutdownLift
11-1
0xB1
ANALOG 1 OUT OF RANGE
Analog_1_Out_Of_Range
0x2620
Analog_X_Out_of_Range
Fault Type(s):
1 = above High limit.
2 = below Low limit.
1. Analog 1 input voltage is above
the parameter setting of Analog
1 High.
2. Analog 1 input voltage is below the
parameter setting of Analog 1 Low.
3. See Programmer » Controller
Setup » Inputs » Analog 1.
4. See Programmer » Controller
Setup » Inputs » Congure »
Analog 1 Low / Analog 1 High.
Set:
(1) Input voltage (on pin) is
above the parameter’s set-
point threshold.
(2) Input voltage (on pin) is
below the parameter’s set-
point threshold.
Clear: Return the voltage to
within the allowed range, then
Reset Controller.
Fault Action:
None, unless a fault action
is programmed in VCL.
11-2
0xB2
ANALOG 2 OUT OF RANGE
Analog_2_Out_Of_Range
0x2621
See Analog 1 Out of Range. See Analog 1 Out of Range. See Analog 1 Out of Range.
11-3
0xB3
ANALOG 3 OUT OF RANGE
Analog_3_Out_Of_Range
0x2622
See Analog 1 Out of Range. See Analog 1 Out of Range. See Analog 1 Out of Range.
11-4
0xB4
ANALOG 4 OUT OF RANGE
Analog_4_Out_Of_Range
0x2623
See Analog 1 Out of Range. See Analog 1 Out of Range. See Analog 1 Out of Range.
11-5
0xB5
ANALOG 5 OUT OF RANGE
Analog_5_Out_Of_Range
0x2624
See Analog 1 Out of Range. See Analog 1 Out of Range. See Analog 1 Out of Range.
11-6
0xB6
ANALOG 6 OUT OF RANGE
Analog_6_Out_Of_Range
0x2625
See Analog 1 Out of Range. See Analog 1 Out of Range See Analog 1 Out of Range.
11-7
0xB7
ANALOG 7 OUT OF RANGE
Analog_7_Out_Of_Range
0x2626
See Analog 1 Out of Range. See Analog 1 Out of Range. See Analog 1 Out of Range.
11-8
0xB8
ANALOG 8 OUT OF RANGE
Analog_8_Out_Of_Range
0x2627
See Analog 1 Out of Range. See Analog 1 Out of Range. See Analog 1 Out of Range.
11-11
0xBB
ANALOG 14 OUT OF RANGE
Analog_14_Out_Of_Range
0x262A
See Analog 1 Out of Range. See Analog 1 Out of Range. See Analog 1 Out of Range.
