4 — PROGRAMMABLE PARAMETERS
pg. 81
Return to TOC Curtis AC F4-A Motor Controller – August 2020
APPLICATION SETUP/VEHICLE — SPEED/DIST/ACCEL MENU
PARAMETER ALLOWABLE RANGE DEFAULT DESCRIPTION
Capture Speed 1
Capture_Speed_1
0x37C4 0x00
0 – 8000 rpm
0 – 8000
4500 The controller captures the time it takes the motor to go from 0
rpm to the programmed Capture Speed. This timer starts every
time the motor accelerates from zero speed.
The result is stored as “Time to Speed 1” in the Programmer
System Monitor » Vehicle » Speed/Dist/Accel menu.
Capture Speed 2
Capture_Speed_2
0x37C5 0x00
0 – 8000 rpm
0 – 8000
4500 This parameter allows a second capture speed to be dened,
and works identically to Capture Speed 1.The result is stored as
“Time to Speed 2” in the Programmer System Monitor » Vehicle »
Speed/Dist/Accel menu.
Capture Distance 1
Capture_Distance_1
0x37C1 0x00
1 – 1320
1 – 1320
22 The controller captures the time it takes the vehicle to travel from
0 rpm to the programmed Capture Distance. The result is stored
as “Time to Dist 1” in the Programmer System Monitor » Vehicle
» Speed/Dist/Accel menu. This timer starts every time the vehicle
accelerates from zero speed.
Note: For accurate distance measuring, the Speed to RPM
parameter must be set correctly.
With the Metric Units parameter programmed Off, distance is in
units of feet. With Metric Units programmed On, distance is in
units of meters.
Capture Distance 2
Capture_Distance_2
0x37C2 0x00
1 – 1320
1 – 1320
100 This parameter allows a second capture distance to be dened,
and works identically to Capture Distance 1. The result is stored
as “Time to Dist 2” in the Programmer System Monitor » Vehicle »
Speed/Dist/Accel menu.
Capture Distance 3
Capture_Distance_3
0x37C3 0x00
1 – 1320
1 – 1320
150 This parameter allows a second capture distance to be dened,
and works identically to Capture Distance 1. The result is stored
as “Time to Dist 3” in the Programmer System Monitor » Vehicle »
Speed/Dist/Accel menu.
Trip Odometer 1
Trip_Odometer_1
0x37D7 0x00
0.0 – 10000000.0
0 – 100000000
Read Only Vehicle distance traveled, in units of miles or km, depending
on the setting of the Metric Units parameter in the Vehicle
parameters menu.
For accurate distance measurements, the Speed to RPM
parameter must be set correctly.
Trip Odometer 2
Trip_Odometer_2
0x37D8 0x00
0.0 – 10000000.0
0 – 100000000
Read Only A second vehicle distance traveled variable, and works identically
to Trip Odometer 1.
TripMarkerOdo1
Trip_Marker_Odo_1_Hund
0x37D5 0x00
–2147483648 –
2147483647
–2147483648 –
2147483647
0 Trip odometer 1.
TripMarkerOdo2
Trip_Marker_Odo_2_Hund
0x37D6
–2147483648 –
2147483647
–2147483648 –
2147483647
0 Trip odometer 2.
Vehicle Acceleration
Vehicle_Acceleration
0x37D9 0x00
0.000 – 10.000 g
0 – 10000
Read Only Vehicle acceleration. This is a calculated value. For an accurate
measurement, correctly set the Speed to RPM parameter
Time to Speed 1
Time_to_Capture_Speed_1
0x37D3 0x00
0.00 – 128.00 s
0 – 32000
Read Only Time taken for the vehicle to go from zero rpm to the
programmed Capture Speed 1 during its most recent such
acceleration.
Time to Speed 2
Time_to_Capture_Speed_2
0x37D4 0x00
0.00 – 128.00 s
0 – 32000
Read Only Time taken for the vehicle to go from zero rpm to the
programmed Capture Speed 2 during its most recent such
acceleration.
