4 — PROGRAMMABLE PARAMETERS
Curtis AC F4-A Motor Controller – August 2020 Return to TOC
pg. 84
APPLICATION SETUP — TRAVEL CONTROL SUPERVISION MENU
PARAMETER ALLOWABLE RANGE DEFAULT DESCRIPTION
Travel Control Supervision
Enable
Travel_Control_Fault_Enable
0x37B1 0x00
On/Off
On/Off
On Enables Travel Control checking. Travel Control is a safety
function that checks that the vehicle is not started from a stopped
state (at rest) on level ground unless the controls for speed and
direction are activated. For the motor controllers, the stopped
state condition is dened as the state where the vehicle is at rest
and the interlock signal is disabled (e.g., tiller up).
If enabled, when the vehicle is in a stopped state (it is at
rest), when the Travel_Control_Stopped_State_Timer >=
Travel_Control_Stopped_State_Time, the controller will monitor
the motor-control electrical frequency and motor-phase current
(Irms) to ensure they stay below their respective limits set by the
Travel Control Max Frequency and Travel Control Max Current
parameters (below). If they do not, the controller triggers the
Travel Control Supervision fault after 64ms. The Stopped State
is exited if ABS_Throttle_Command > 1 (i.e., valid throttle
command, either forward or reverse).
Travel Control Stopped State
Timer
Travel_Control_Stopped_State_
Timer
0x37B0 0x00
–2147484.00 –
2147484.00
–2147483648 –
2147483647
Read Only
Sec
Shows timer, in 0.01 seconds, for entering stopped state.
This variable is useful for setting up the Travel Control
Supervision parameters.
Travel Control Stopped State
Time
Travel_Control_Stopped_State_
Time
0x37AD 0x00
0.1 – 10.0 s
100 – 10000
0.1 Sec The time when the vehicle is at zero speed before it enters
the stopped state and begins checking for the Travel Control
Fault conditions.
Travel Control Max Frequency
Travel_Control_Max_Frequency
0x37AE 0x00
1.0 – 40.0 Hz
60 – 2400
20.0 Hz The controller’s maximum motor-control electrical frequency
when in the stopped state before the Travel Control Supervision
fault is declared.
Travel Control Max Current
Travel_Control_Max_Current
0x37AF 0x00
0.1 – 100.0 A
1 – 1000
50.0 Amps The controller’s maximum motor-phase current (Irms) when in
stopped state before the Travel Control Supervision fault
is declared.
