4 — PROGRAMMABLE PARAMETERS
Curtis AC F4-A Motor Controller – August 2020 Return to TOC
pg. 86
CONTROLLER SETUP — INPUTS MENU
PARAMETER ALLOWABLE RANGE DEFAULT DESCRIPTION
PWM Input 10 Type
PWM_Input_10_Type
0x5088 0x00
0 – 2
0 – 2
0 Input 10 (pin 10) is a high frequency input for either duty-cycle
or frequency signals. When not using the PWM input options, the
input operates as a switch input.
0 – The PWM Input is not used, and disables fault checking
on this PWM input. The switch setting.
1 – The PWM Input measurement normalized to duty cycle
low/high range.
2 – The PWM Input measurement normalized to frequency
low/high range.
PWM Input 10 Type = (2) duty cycle or (3) frequency
These PWM Input 10 monitor and parameter items are only visible when options 1 or 2 are selected
These items are visible within the Programmer app, Controller Setup » Inputs » PWN Input 10 menu
PWN Input 10 menu
Duty Cycle
PWM_Input_10_Cycle
0x3B69 0x00
0.0 – 100.0 %
0 – 1000
Read Only
0.0 %
PWM Input 10 duty cycle measurement.
Percent
PWM_Input_10_Percent
0x3192 0x00
0.0 – 100.0 %
0 – 1000
Read Only
0.0 %
PWM input 10 as a percentage of congured type (duty cycle, or
frequency). 0% maps to min, 100% maps to max.
Frequency
PWM_Input_10_Frequency
0x3B67 0x00
0 – 10000
0 – 10000
Read Only
0 Hz
PWM Input frequency measurement.
Duty Cycle Low
PWM_Input_10_Low_Duty_
Cycle
0x5080 0x00
0 – 100 %
0 – 1000
0 % PWM Input low duty cycle threshold.
Duty Cycle High
PWM_Input_10_High_Duty_
Cycle
0x5081 0x00
0 – 100 %
0 – 1000
100 % PWM Input high duty cycle threshold.
Note: Do not set the high value lower than the corresponding low
value.
Frequency Low
PWM_Input_10_Low_
Frequency
0x5082 0x00
500 – 10000 Hz
500 – 10000
500 Hz PWM Input low frequency threshold.
Frequency High
PWM_Input_10_High_
Frequency
0x5083 0x00
0 – 10000 Hz
0 – 10000
10000 Hz PWM Input high frequency threshold.
Note: Do not set the high value lower than the corresponding low
value.
