Curtis PMC 1297 Manual
53
HYD THRTL MAX
The hydraulic throttle maximum parameter sets the throttle wiper voltage
required to produce 100% controller output. Decreasing the hydraulic Throttle
Max setting reduces the wiper voltage and therefore the full stroke necessary to
produce full controller output. This feature allows reduced-range throttle
assemblies to be accommodated.
Examples are shown in Figure 22 for throttle types 2 and 4. These
examples illustrate the effect of three different Throttle Max settings (100%,
90%, 60%) on the full-stroke wiper voltage required to attain 100% controller
output.
Fig. 22 Effect of adjusting
the hydraulic Throttle Max
parameter.
3 B — PROGRAMMABLE HYDRAULIC PARAMETERS: Hydraulic Throttle
Throttle Type 2 (0–5V, single-ended)
Throttle Type 4 (0–5V, wigwag)
Note: Voltages shown are at the pot wiper relative to B-.
KEY
100%
Neutral
Deadband
Controller
Output
0%
0
5V
100% Throttle Max
40% Deadband
90% Throttle Max
40% Deadband
90% Throttle Max
10% Deadband
60% Throttle Max
10% Deadband
0
5V
100% Throttle Max
40% Deadband
90% Throttle Max
40% Deadband
90% Throttle Max
10% Deadband
60% Throttle Max
10% Deadband
2.1V
0.7V
4.5V
0.7V
3.1V
2.1V
4.5V
0.2V
3.3V
4.5V
0.5V
1.7V
3.3V
4.3V
0.7V
1.7V
2.7V
4.3V
0.7V
2.3V
2.7V
3.7V
1.3V
2.3V
