Curtis PMC 1297 Manual
83
Preliminary on Verso page is set with right edge at 7 and 7/8,
and the top (as on the Recto page) at 1/4.
6 — PROGRAMMER MENUS: Diagnostics Menu
1297 DIAGNOSTICS AND DIAGNOSTIC HISTORY
This is a list of the possible messages you may see displayed when the program-
mer is operating in either of the Diagnostics modes. The messages are listed here
in alphabetical order for easy reference.
ANALOG MUX FAULT Multiplexer communications interrupted
ANTI-TIEDOWN Mode switch closed (M2) at startup
BDI LOW Battery state of charge <20%
DRIVE M- Traction motor terminal shorted to B- or open
DRIVE SENSOR Traction motor current sensor error
EMR REV WIRING Emergency reverse wiring fault
FIELD OPEN Traction motor field winding open
FIELD SHORT Traction motor field overcurrent
HPD HPD fault occurred
HW FAILSAFE Hardware failsafe activated
HYD INHIBIT Hydraulic throttle high at interlock
HYD THROTTLE FAULT Hydraulic throttle fault
LOW BATTERY VOLTAGE Battery voltage too low
MAIN CONT WELDED Main contactor welded
MISSING CONTACTOR Main contactor missing
NO KNOWN FAULTS No known faults
OVER TEMP CUTBACK Cutback due to internal temp >85°C
OVERVOLTAGE Battery voltage too high
PUMP DISABLED Pump motor disable timer expired
PUMP M- Pump motor terminal shorted to B- or open
PUMP SENSOR Pump motor current sensor error
SERVICE PUMP Pump motor service timer expired
SERVICE TOTAL Total service timer expired
SERVICE TRAC Traction motor service timer expired
SRO SRO fault occurred
THROTTLE WIPER HI Traction throttle wiring fault (high)
THROTTLE WIPER LO Traction throttle wiring fault (low)
TOTAL DISABLED Total disable timer expired
TRAC DISABLED Traction motor disable timer expired
UNDER TEMP CUTBACK Cutback due to internal temp <-25°C
VALVE FAULT Lowering valve fault
