Curtis PMC 1297 Manual
88
Preliminary on Verso page is set with right edge at 7 and 7/8,
and the top (as on the Recto page) at 1/4.
7 — DIAGNOSTICS & TROUBLESHOOTING
SPYGLASS DIAGNOSTICS
The eight-character LCD on the Spyglass displays a continuous sequence of
hourmeter, battery state-of-charge, and fault messages.
Fault messages are displayed using the same codes that are flashed by the
LED. For example, the LED flashes 3,2 for a welded main contactor:
¤¤¤ ¤¤ ¤¤¤ ¤¤ ¤¤¤ ¤¤
( 3 , 2 ) ( 3 , 2 ) ( 3 , 2 )
and the corresponding Spyglass message is CODE 32.
