6 — PROGRAMMER MENUS: Program Menu
6
PROGRAMMER MENUS
The universal 13XX Curtis PMC programmers allow you to program, test, and
diagnose Curtis PMC programmable controllers. For further information about
programmer operation, consult the programmer manual or call the Curtis office
closest to you.
There are five programmer menus:
• Program Menu
• Test Menu
• Diagnostics Menu
• Special Diagnostics (Diagnostic History File)
• Special Program Menu.
The first four menus are controller-specific, and are presented below. The items
are listed in these menus in the order in which they appear in the actual menus
displayed by the 13XX programmer. Depending on the specific 1297 model you
have, some of the items may not appear.
The “special” program menu is generic to the various controllers, and is
therefore not covered here; see the programmer manual.
1297 PROGRAM MENU (not all items available on all controllers)
M1 DRIVE C/L Mode 1 drive current limit, in amps
M2 DRIVE C/L Mode 2 drive current limit, in amps
M1 BRAKE C/L Mode 1 braking current limit, in amps
M2 BRAKE C/L Mode 2 braking current limit, in amps
M1 ACCEL RATE Mode 1 acceleration rate, in seconds
M2 ACCEL RATE Mode 2 acceleration rate, in seconds
M1 DECEL RATE Mode 1 deceleration rate, in seconds
M2 DECEL RATE Mode 2 deceleration rate, in seconds
M1 BRAKE RATE Mode 1 braking rate during direction change, in seconds
M2 BRAKE RATE Mode 2 braking rate during direction change, in seconds
M1 MAX SPEED Maximum speed in Mode 1, as % armature PWM
M2 MAX SPEED Maximum speed in Mode 2, as % armature PWM
CREEP SPEED Creep speed, as % armature PWM
THROTTLE DECEL Time for transition to braking mode, in seconds
COAST DECEL Deceleration rate for coast mode after Pick release, in seconds
INT BRAKE C/L Interlock braking current limit, in amps
INT BRAKE RATE Interlock braking rate, in seconds
INT BRAKE DLY Interlock braking delay, in seconds
