1297 TEST MENU
(not all items available on all controllers)
BATT VOLTAGE Battery voltage across B+ and B-, in volts
BDI % Battery state of charge, as % of full charge
HEATSINK TEMP Heatsink temperature, in °C
THROTTLE % Throttle reading, as % of full throttle
FIELD CURRENT Traction motor field current, in amps
ARM CURRENT Traction motor armature current, in amps
FIELD PWM Traction motor field duty cycle, as %
ARM PWM Traction motor armature duty cycle, as %
FORWARD INPUT Forward switch: on/off [neutral switch for Type 4 throttle]
REVERSE INPUT Reverse switch: on/off
MODE INPUT Mode switch: on (M2)/off (M1)
EMR REV INPUT Emergency reverse switch: on/off
HYD THROTTLE % Hydraulic throttle reading, as % of full throttle
PUMP CURRENT Pump motor current, in amps
PUMP PWM Pump motor duty cycle, as %
LV CURRENT Lowering valve current, in amps
LV PWM Lowering valve duty cycle, as %
LIFT INPUT Lift switch: on/off
LOWER INPUT Lower switch: on/off
MAIN CONT Main contactor: open/closed
E-M BRAKE Electromagnetic brake: on/off
HORN INPUT Horn driver: on/off
LOAD HOLD Load-hold valve driver: on/off
6 — PROGRAMMER MENUS: Test Menu
