Program Menu Notes
1
Traction throttle types (see Throttle Wiring in Section 2)
Type 1: 5kΩ–0
Type 2:
single-ended 0–5V throttles and 3-wire pots
Type 3: 0–5kΩ
Type 4:
wigwag 0–5V throttles and 3-wire pots
2
HPD types (see Section 3A, page 44)
Type 0: No HPD.
Type 1: HPD unless KSI
and interlock inputs received before throttle request.
Type 2: HPD unless KSI input is received before throttle request.
3
SRO types (see Section 3A, page 45)
Type 0: No SRO.
Type 1: SRO unless interlock input is received before a direction is selected.
Type 2: SRO unless KSI + interlock inputs received before direction selected.
Type 3: SRO unless KSI + interlock +
forward inputs received in that order.
4
Main contactor control types (see Section 3C, page 57)
On: Interlock switch input required in addition to KSI to close contactor.
Off: Contactor closes on KSI input alone.
5
Electromagnetic brake driver types (for detail on options, see Table 2, page 30)
Type 0: no electromagnetic brake driver
Type 1: Option 1
Type 2: Option 2
Type 3: Option 3
Type 4: Option 4
6
Emergency reverse exit control type
(see Section 3
A, page 42)
On: To resume normal operation after emergency reversing has been
completed, the operator can either open both direction switches
or
cycle the interlock switch.
Off: To resume normal operation after emergency reversing has been
completed, the operator must cycle the interlock switch.
7
Hydraulic throttle types (see Hydraulic Throttle Wiring in Section 2)
Type 2:
single-ended 0–5V throttles and 3-wire pots
Type 4:
wigwag 0–5V throttles and 3-wire pots
6 — PROGRAMMER MENUS: Program Menu
