80
Preliminary on Verso page is set with right edge at 7 and 7/8,
and the top (as on the Recto page) at 1/4.
HYD THRTL MAX % of pump throttle movement at which 100% output occurs
HYD THRTL MAP Throttle map, as % pump motor PWM at half pump throttle
VARIABLE LIFT Enables variable Lift: on/off
VARIABLE LOWER Enables variable Lower: on/off
PUMP MAX SPEED Pump max. speed during Lift, as % armature PWM
NO LOAD SPEED Pump max. speed in no-load Lift, as % armature PWM
PUMP BDI L/O Lift lockout when battery S-O-C <20%: on/off
PUMP BDI WRN Horn beeps at Lift request if battery S-O-C <25%: on/off
HYD INHIBIT Hydraulic lockout if throttle >25% at interlock: on/off
LOAD HOLD DLY Delay after Lift/Lower, in seconds
LV CHECK Lowering valve check: on/off
LV ACCEL Acceleration rate for lowering valve current, in seconds
LV DECEL Deceleration rate for lowering valve current, in seconds
LV MIN C/L Minimum current for lowering valve, in amps
LV MAX C/L Maximum current for lowering valve, in amps
LV DITHER I
LVcoil
dither for lowering valve, in % LV maximum current
ADJ HOURS HIGH Hourmeter preset high byte: 0–151
ADJ HOURS MID Hourmeter preset middle byte: 0–255
ADJ HOURS LOW Hourmeter preset low byte: 0–255
SET TOTL HRS Apply preset values to total hourmeter: on/off
SET TRAC HRS Apply preset values to traction hourmeter: on/off
SET PUMP HRS Apply preset values to pump hourmeter: on/off
SRVC TOTL HRS Total service timer setting, in hours
SRVC TRAC HRS Traction service timer setting, in hours
SRVC PUMP HRS Pump service timer setting, in hours
DIS TOTL HRS Total disable timer setting, in hours
DIS TRAC HRS Traction disable timer setting, in hours
DIS PUMP HRS Pump disable timer setting, in hours
TRAC FAULT SPD Max. drive speed if disable timer expires, as % Max Speed
PUMP FAULT SPD Max. pump speed if disable timer expires, as % Lift Max Speed
SERVICE TOTL Reset total service timer: on/off
SERVICE TRAC Reset traction service timer: on/off
SERVICE PUMP Reset pump service timer: on/off
FULL VOLTS Voltage considered 100% state of charge, in volts
EMPTY VOLTS Voltage considered 0% state of charge, in volts
RESET VOLTS Voltage at which state of charge resets to 100%, in volts
MUX ENABLE Multiplexer inputs enabled: on/off
Program Menu, cont’d
6 — PROGRAMMER MENUS: Program Menu
