24 EZ-USB Development Kit User Guide, Doc. # 001-66390 Rev. *D
Advanced Development Board
Table 3-7. Pin Designation (P4)
Table 3-8. Pin Designation (P5)
Table 3-9. Pin Designation (P6)
Alternate Default P4 Default Alternate
NC 1 2 3.3 V
CLKOUT 3 4 GND
OE# 5 6 CS#
5V 7 8 5V
PLD2 9 10 PLD1
N.C. 11 12 D7
D6 13 14 D5
D4 15 16 D3
D2 17 18 D1
D0 19 20 GND
Alternate Default P5 Default Alternate
NC 1 2 3.3 V
IFCLK 3 4 A15
A14 5 6 A13
A12 7 8 A11
A10 9 10 A9
A8 11 12 A7
A6 13 14 A5
A4 15 16 A3
A2 17 18 A1
A0 19 20 GND
Alternate Default P6 Default Alternate
NC 1 2 3.3 V
RD# 3 4 INT5#
INT4 5 6 T2
T1 7 8 T0
WAKEUP# 9 10 SDA
SCL 11 12 PE7 GPIFADR8
T2EX PE6 13 14 PE5 INT6
RxD1OUT PE4 15 16 PE3 RxD0OUT
T2OUT PE2 17 18 PE1 T1OUT
T0OUT PE0 19 20 GND
