xStack
®
DGS-3600 Series Layer 3 Managed Gigabit Ethernet Switch
BGP Peer Group Settings
This window is used to create or delete a Border Gateway Protocol (BGP) neighbor.
To view this window, click L3 Features > BGP > BGP Peer Group Settings, as shown below:
Figure 4- 137. BGP Peer Group Settings window
To configure BGP peer group settings on the Switch, complete the following fields:
Parameter Description
Peer Group Name
Enter the name of the BGP peer group.
Action
Choose among None, Add, or Delete. None is the default.
IP Address
Enter the IP address to be added or deleted.
Remote AS Number
(0-65535)
Enter the number of the autonomous system to which the peer group belongs to. The range
is from 0 to 65535.
Click Apply to implement changes made.
277
