Current Configuration Settings
The Current Configuration Settings window allows users to manipulate configuration images saved in the Flash memory of the
Switch.
To view this window, click Save Services > Current Configuration Settings, as shown below:
Figure 9- 5. Current Configuration Settings window
This window offers the following information:
Parameter Description
Configuration File
Enter the configuration file located on the Flash drive to be altered.
Action
This field has two options for configuration.
Boot – Select this option to set the configuration file specified above as the boot up
configuration for the Switch. This saved configuration will be set as the boot up file
after a switch reboot has been performed. The default setting has configuration file
C:/STARTUP.CFG as the boot up configuration file for the Switch unless specified
here.
Active - Choosing this parameter will first load and then activate this configuration file on
the Switch.
Click Apply to implement changes made.
Logout
Use the Logout page to logout of the Switch's Web-based management agent by clicking on the Logout button.
Figure 9- 6. Logout window
