xStack
®
DGS-3600 Series Layer 3 Managed Gigabit Ethernet Switch
System Log Save Mode Settings
This window may be used to choose a method for which to save the switch log to the flash memory of the Switch.
To view this window, click Administration > System Log > System Log Save Mode Settings, as shown below:
Figure 2- 26. System Log Save Mode Settings window
The following parameters can be configured:
Parameter Description
Save Mode
Use the pull-down menu to choose the method for saving the switch log to the Flash memory.
There are three options:
Time Interval – Configure a time interval by which the switch will save the log files.
On Demand – Only save log files when manually telling the Switch to do so. Go to Save
Services > Save Changes to manually save log.
On Trigger – Save log files to the Switch every time when a log event occurs on the Switch.
Minute(s)
When Time Interval is selected in Save Mode, set a time between 1 and 65535 minutes in the
field. The default value is 1 minute.
Click Apply to implement the changes. Click Save Log Now to immediately save log files currently on the Switch.
System Log Source Interface Settings
This window is used to configure syslog source interface settings.
To view this window, click Administration > System Log > System Log Source Interface Settings, as shown below:
Figure 2- 27. Syslog Source Interface Settings window
29
