xStack
®
DGS-3600 Series Layer 3 Managed Gigabit Ethernet Switch
Appendix D
Module Specs and Cable Lengths
Use the following table to as a guide for the module specs and maximum cable lengths.
Standard Media Type Maximum Distance
Mini-GBIC 1000BASE-LX, Single-mode fiber module
1000BASE-SX, Multi-mode fiber module
1000BASE-LH, Single-mode fiber module
1000BASE-ZX, Single-mode fiber module
10km
550m / 2km
50km
80km
1000BASE-T Category 5e UTP Cable 100m
100BASE-TX Category 5 UTP Cable (100 Mbps) 100m
10BASE-T Category 3, 4 or 5 UTP Cable (10 Mbps) 100m
DEM-310GT 1000Base-LX, Single-mode 10km
DEM-311GT 1000ase-SX, Multi-mode 500m
DEM-312GT2 1000Base-SX, Multi-mode 2km
DEM-314GT 1000BASE-LH, Single-mode 50km
DEM-315GT 1000BASE-ZX, Single-mode 80km
DEM-210 100BASE-FX, Single-mode 15km
DEM-211 100BASE-FX, Multi-mode 2km
DEM-330T TX-1550/RX-1310nm, Single-mode up to 10km
DEM-330R TX-1310/RX-1550 nm, Single-mode up to 10km
DEM-331T TX-1550/RX-1310 nm, Single-mode up to 40km
DEM-331R TX-1310/RX-1550 nm, Single-mode up to 40km
DEM-410CX 10-Gigabit CX4 module, Infiniband 4X latch-type
cable
1 and 3 meters
DEM-410X 10-Gigabit XFP module *distance depends on
transceiver type
DEM-421 850mn Multi-mode XFP transceiver
DEM-422 1310mn, Single-mode XFP transceiver
Network pluggable optical modules meet the following regulatory requirements:
• Class 1 Laser Product
• EN60825-1+A2:2001 or later, European laser standard
• FCC 21 CFR Chapter 1, Subchapter J in accordance with FDA & CDRH requirements
485
