D-Link DIR-816L User Manual

DIR-816L Wireless AC750 Dual Band Router & Access Point
with 3G/CDMA/LTE Support and USB Port
User Manual
Overview
Wireless Module Parameters
Transmitter output power
The maximum value of the transmitter
output power depends upon the radio
frequency regulations applied in your
country
· 802.11a (typical at room temperature 25 °C)
16dBm (+/-2dB) at 6, 9, 12, 18, 24Mbps
15dBm (+/-2dB) at 36Mbps
14dBm (+/-2dB) at 48, 54Mbps
· 802.11b (typical at room temperature 25 °C)
16dBm (+/-2dB) at 1, 2, 5.5, 11Mbps
· 802.11g (typical at room temperature 25 °C)
16dBm (+/-2dB) at 6, 9, 12, 18, 24, 36Mbps
15dBm (+/-2dB) at 48Mbps
14dBm (+/-2dB) at 54Mbps
· 802.11n (typical at room temperature 25 °C)
2.4GHz, HT20
16dBm (+/-2dB) at MCS0/1/2/3/4, MCS8/9/10/11/12
15dBm (+/-2dB) at MCS5, MCS13
14dBm (+/-2dB) at MCS6/7, MCS14/15
2.4GHz, HT40
16dBm (+/-2dB) at MCS0/1/2/3/4, MCS8/9/10/11/12
15dBm (+/-2dB) at MCS5, MCS13
14dBm (+/-2dB) at MCS6/7, MCS14/15
5GHz, HT20
16dBm (+/-2dB) at MCS0/1/2/3/4
15dBm (+/-2dB) at MCS5
14dBm (+/-2dB) at MCS6/7
5GHz, HT40
16dBm (+/-2dB) at MCS0/1/2/3/4
15dBm (+/-2dB) MCS5
14dBm (+/-2dB) MCS6/7
· 802.11ac (typical at room temperature 25 °C)
HT20
16dBm (+/-2dB) at MCS0/1/2/3/4
15dBm (+/-2dB) at MCS5
14dBm (+/-2dB) at MCS6/7
12dBm (+/-2dB) at MCS8
HT40
16dBm (+/-2dB) at MCS0/1/2/3/4
15dBm (+/-2dB) at MCS5
14dBm (+/-2dB) at MCS6/7
12dBm (+/-2dB) at MCS8
11dBm (+/-2dB) at MCS9
HT80
16dBm (+/-2dB) at MCS0/1/2/3/4
15dBm (+/-2dB) at MCS5
14dBm (+/-2dB) at MCS6/7
12dBm (+/-2dB) at MCS8
11dBm (+/-2dB) at MCS9
Receiver sensitivity
· 802.11a (typical at PER = 10% (1000-byte PDUs) at room temperature 25 °C)
-82dBm at 6Mbps
-81dBm at 9Mbps
-79dBm at 12Mbps
-77dBm at 18Mbps
-74dBm at 24Mbps
-70dBm at 36Mbps
-66dBm at 48Mbps
-65dBm at 54Mbps
· 802.11b (typical at PER = 8% (1000-byte PDUs) at room temperature 25 °C)
-79dBm at 11Mbps
-82dBm at 5.5Mbps
-84dBm at 2Mbps
-84dBm at 1Mbps
Page 10 of 304

D-Link DIR-816L Specifications

General

VPN support	Multi-sessions PPtP / l2tP / iPsec
Ethernet LAN	Yes
Cabling technology	10/100Base-T(X)
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3u
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
USB version	2.0
Rack mounting	No
Bandwidth (first)	2.4 GHz
Bandwidth (second)	5 GHz
USB ports quantity	1
Ethernet LAN (RJ-45) ports	4
DHCP client	-
Antennas quantity	2
Security algorithms	WPA, WPA2, WPS
Product color	Black

Weight and Dimensions

Depth	112 mm
Width	151.6 mm
Height	30.5 mm
Weight	204 g
