DIR-816L Wireless AC750 Dual Band Router & Access Point
with 3G/CDMA/LTE Support and USB Port
User Manual
Configuring Device (Router Mode)
Creating PPPoE WAN Connection
To create a connection of the PPPoE type, click the Add button on the Net / WAN page. On the
opened page, select the PPPoE value from the Connection Type drop-down list and specify the
needed values.
Figure 71. The page for creating a new PPPoE connection. The General settings section.
Parameter Description
General settings
Provider Leave the Manually value.
Interface
A physical or virtual interface to which the new connection will be
assigned.
Name A name for connection for easier identification.
Enable Select the checkbox to enable the connection.
Direction The direction of this connection.
Page 95 of 304
