DIR-816L Wireless AC750 Dual Band Router & Access Point
with 3G/CDMA/LTE Support and USB Port
User Manual
Configuring Device (Router Mode)
Creating LTE WAN Connection
!
For the USB modem Megafon M100-1, please reboot the router after creating the WAN
connection.
To create a connection of the LTE type, click the Add button on the Net / WAN page. On the
opened page, select the relevant value from the Connection Type drop-down list and specify the
needed values.
Figure 107. The page for creating a new LTE connection. The General settings section.
Parameter Description
General settings
Provider Leave the Manually value.
Interface Select the USB value.
Name A name for connection for easier identification.
Enable Select the checkbox to enable the connection.
Direction The direction of this connection.
Page 131 of 304
