DIR-816L Wireless AC750 Dual Band Router & Access Point
with 3G/CDMA/LTE Support and USB Port
User Manual
Configuring Device (Router Mode)
IPv6 Routing
On the Advanced / IPv6 routing page, you can add static routes (routes for networks that are not
connected directly to the device but are available through the interfaces of the device) into the
system.
Figure 139. The Advanced / IPv6 routing page.
To create a new route, click the Add button. In the line displayed, you can specify the following
parameters:
Parameter Description
Destination network
A destination network to which this route is assigned. You can specify
an IPv6 address (2001:db8:1234::1) or an IPv6 address with a
prefix (2001:db8:1234::/64).
Gateway
An IPv6 address through which the destination network can be
accessed.
Metric
A metric for the route. The lower the value, the higher is the route
priority. Optional.
After specifying the needed parameters, click the Apply button.
To edit an existing route, select a needed field in the relevant line of the table, change its value, and
click the Apply button.
To remove an existing route, select the checkbox located to the left of the relevant line in the table
and click the Delete button. Then click the Apply button.
Page 176 of 304
