DIR-816L Wireless AC750 Dual Band Router & Access Point
with 3G/CDMA/LTE Support and USB Port
User Manual
Configuring Device (Router Mode)
UPnP IGD
On the Advanced / UPnP IGD page, you can enable the UPnP IGD protocol. The router uses the
UPnP IGD protocol for automatic configuration of its parameters for network applications requiring
an incoming connection to the router.
Figure 133. The Advanced / UPnP IGD page.
If you want to manually specify all parameters needed for network applications, deselect the
Enabled checkbox and click the Apply button.
If you want to enable the UPnP IGD protocol in the router, select the Enabled checkbox and click
the Apply button.
When the protocol is enabled, the router's parameters configured automatically are displayed on the
page:
Parameter Description
Protocol A protocol for network packet transmission.
IP
The IP address of a client from the local area network.
Private port
A port of a client's IP address to which traffic is directed from a
public port of the router.
Public port
A public port of the router from which traffic is directed to a client's
IP address.
Comments Information transmitted by a client's network application.
Page 169 of 304
