DIR-816L Wireless AC750 Dual Band Router & Access Point
with 3G/CDMA/LTE Support and USB Port
User Manual
Configuring Device (Router Mode)
Parameter Description
VLAN ID
An identifier of the VLAN to which this group of ports will be
assigned.
QoS A priority tag for the type of traffic transmitted.
Tagged port
From the list, select an available value to assign it to this group.
Untagged ports
The section includes the ports (a physical port of the router, the
wireless interface, or, if the wireless network is splitted into parts, a
part of the wireless network) that can be added to the group.
To add a port to the group, select the needed checkbox located to the
left of the relevant port.
To remove a port from the group, deselect the needed checkbox
located to the left of the relevant port.
Click the Apply button.
To edit or remove an existing group, select the relevant group on the Advanced / VLAN page. On
the page displayed, change the parameters and click the Apply button, or click the Delete button.
