DIR-816L Wireless AC750 Dual Band Router & Access Point
with 3G/CDMA/LTE Support and USB Port
User Manual
Configuring Device (Router Mode)
CHAPTER 4. CONFIGURING DEVICE (ROUTER
MODE)
Monitoring
The page displays an interactive scheme which illustrates the router's settings and the LAN
structure.
Figure 24. The Monitoring page.
Also you can modify the basic parameters of the router on the Monitoring page. To access the
router's advanced settings, click the Editing device settings link in the bottom left corner of the
page. For the detailed description of all the router's functions, see the relevant section of this
manual.
Page 44 of 304
