DIR-816L Wireless AC750 Dual Band Router & Access Point
with 3G/CDMA/LTE Support and USB Port
User Manual
Configuring Device (Router Mode)
Creating PPPoE + Static IP or PPPoE + Dynamic IP WAN Connection
To create a connection of the PPPoE + Static IP or PPPoE + Dynamic IP type, click the Add button
on the Net / WAN page. On the opened page, select the relevant value from the Connection
Type drop-down list and specify the needed values.
Figure 91. The page for creating a new PPPoE + Static IP connection. The General settings section.
Parameter Description
General settings
Provider Leave the Manually value.
Interface
A physical or virtual interface to which the new connection will be
assigned.
Name A name for connection for easier identification.
Enable Select the checkbox to enable the connection.
Direction The direction of this connection.
Page 114 of 304
