DIR-816L Wireless AC750 Dual Band Router & Access Point
with 3G/CDMA/LTE Support and USB Port
User Manual
Configuring Device (Router Mode)
Figure 101. The page for creating a new PPTP + Static IP connection. The Authorization via 802.1x
protocol section.
Parameter Description
Authorization via 802.1x protocol
Authorization in the
ISP’s network via
802.1x protocol
Select the checkbox to allow authorization in the ISP's network via
the 802.1x protocol.
Authentication
method
Select a needed authentication method from the drop-down list.
Username
Enter the username provided by your ISP.
Password
Enter the password provided by your ISP.
Isolate connection
When the checkbox is selected, the router uses an alternate routing
table for this connection. Select the checkbox only when your ISP
requires this.
Enable RIP
Select the checkbox to allow using RIP for this connection.
Enable IGMP Multicast
Select the checkbox to allow multicast traffic from the external
network (e.g. video streaming) to be received.
NAT
Select the checkbox if you want one WAN IP address to be used for
all computers of your LAN.
Firewall
Select the checkbox to enable protection against ARP and DDoS
attacks.
Ping
Select the checkbox to allow the router to answer ping requests
from the external network through this connection. For security
reasons, it is recommended not to select this checkbox.
Page 124 of 304
