DIR-816L Wireless AC750 Dual Band Router & Access Point
with 3G/CDMA/LTE Support and USB Port
User Manual
Configuring Device (Router Mode)
When the Open or Shared value is selected, the WEP Encryption settings section is displayed
(the section is unavailable for the wireless network operating modes which support the standard
802.11n):
Figure 120. The Open value is selected from the Network Authentication drop-down list.
Parameter Description
Enable Encryption WEP
The checkbox activating WEP encryption. When the checkbox is
selected, the Default Key ID field, the Encryption Key WEP as
HEX checkbox, the WEP key length drop-down list, and four
Encryption Key WEP fields are displayed on the page. For the
Shared authentication type the checkbox is always selected.
Default Key ID
The number of the key (from first to fourth) which will be used for
WEP encryption.
Encryption Key WEP as
HEX
Select the checkbox to set a hexadecimal number as a key for
encryption.
WEP key length
The length of WEP encryption key.
Select the value 64bit to specify keys containing 5 ASCII symbols
or 10 HEX symbols.
Select the value 128bit to specify keys containing 13 ASCII
symbols or 26 HEX symbols.
Encryption Key WEP (1-
4)
Keys for WEP encryption. The router uses the key selected from the
Default Key ID drop-down list. It is required to specify all the
fields.
Page 147 of 304
