DIR-816L Wireless AC750 Dual Band Router & Access Point
with 3G/CDMA/LTE Support and USB Port
User Manual
Overview
LED Mode Description
WLAN
WPS
Solid green
The 2.4GHz and/or 5GHz bands are on.
Fast blinking green
The WLAN interface is active (upstream or downstream
traffic).
Slow blinking green
Attempting to add a wireless device via the WPS
function.
No light
The 2.4GHz and 5GHz bands are off.
LAN 1-4
Solid green
A device (computer) is connected to the relevant port,
the connection is on.
Blinking green
The LAN port is active (upstream or downstream
traffic).
When the router is being loaded, the LEDs are blinking
one at a time.
When the firmware is being upgraded, the LEDs are
blinking two at a time.
No light
The cable is not connected to the relevant port.
