DIR-816L Wireless AC750 Dual Band Router & Access Point
with 3G/CDMA/LTE Support and USB Port
User Manual
Configuring Device (Router Mode)
Figure 135. The page for changing the settings of the router's port.
On the opened page, select the Manual management checkbox and specify the needed
parameters:
Parameter Description
Duplex
Select data transfer mode from the drop-down list:
Full: Data transfer in two directions simultaneously (data can be
sent and received at the same time).
Half: Data transfer in just one direction at a time (data can be either
sent or received).
Bitrate Data transfer rate (Mbps) for a port.
After specifying the needed parameters, click the Apply button.
If in the future you need to edit the parameters of the router's port, select the port in the table. On
the opened page, change the needed parameters and click the Apply button.
To enable autonegotiation for the router's port again, select the port in the table and deselect the
Manual management checkbox on the opened page. Then click the Apply button.
Page 171 of 304
