DIR-816L Wireless AC750 Dual Band Router & Access Point
with 3G/CDMA/LTE Support and USB Port
User Manual
Configuring Device (Router Mode)
Figure 146. The page for adding an IPsec tunnel.
You can specify the following parameters:
Parameter Description
Dynamic IPsec
Select the checkbox to allow a remote host with any public IP address
to connect to the router via IPsec protocol. The checkbox can be
selected for one tunnel only. Connection requests via the tunnel, for
which this checkbox is selected, can be sent by a remote host only.
Remote address
A remote subnet VPN gateway IP address. The field is available, if the
Dynamic IPsec checkbox is not selected.
Page 185 of 304
