xStack
®
DES-3200 Series Layer 2 Managed Fast Ethernet Switch CLI Reference Guide
452
DES-3200-28P:admin#config ethernet_oam ports 1 link_monitor error_frame
threshold 2 window 1000 notify_state enable
Command: config ethernet_oam ports 1 link_monitor error_frame threshold 2
window 1000 notify_state enable
Success.
DES-3200-28P:admin#
To configure the error frame seconds threshold to 2 and period to 10000 ms for port 1:
DES-3200-28P:admin#config ethernet_oam ports 1 link_monitor error_frame_seconds
threshold 2 window 10000 notify_state enable
Command: config ethernet_oam ports 1 link_monitor error_frame_seconds threshold
2 window 10000 notify_state enable
Success.
DES-3200-28P:admin#
To configure the error frame threshold to10 and period to 1000000 ms for port 1:
DES-3200-28P:admin#config ethernet_oam ports 1 link_monitor error_frame_period
threshold 10 window 1000000 notify_state enable
Command: config ethernet_oam ports 1 link_monitor error_frame_period threshold
10 window 1000000 notify_state enable
Success.
DES-3200-28P:admin#
To configure a dying gasp event for port 1:
DES-3200-28P:admin#config ethernet_oam ports 1 critical_link_event dying_gasp
notify_state enable
Command: config ethernet_oam ports 1 critical_link_event dying_gasp
notify_state enable
Success.
DES-3200-28P:admin#
To start remote loopback on port 1:
DES-3200-28P:admin#config ethernet_oam ports 1 remote_loopback start
Command: config ethernet_oam ports 1 remote_loopback start
Success.
DES-3200-28P:admin#
To configure the method of processing the received remote loopback command as “process” on
port 1:
