xStack
®
DES-3200 Series Layer 2 Managed Fast Ethernet Switch CLI Reference Guide
498
Parameters
<portlist> - (Optional) Specify a range of ports to be displayed.
If no parameter specified, system will display all ports scheduling configurations.
Restrictions
None.
Example
To display the traffic scheduling parameters for each CoS queue on port 1(take eight hardware
priority queues for example):
DES-3200-28P:admin#show scheduling 1
Command: show scheduling 1
QOS Output Scheduling On Port: 1
Class ID Weight
-------- ------
Class-0 1
Class-1 2
Class-2 3
Class-3 4
Class-4 5
Class-5 6
Class-6 7
Class-7 8
DES-3200-28P:admin#
57-8 show scheduling_mechanism
Description
This command is used to show the traffic scheduling mechanism.
Format
show scheduling_mechanism {<portlist>}
Parameters
<portlist> - (Optional) Specify a range of ports to be displayed.
If no parameter specified, system will display all ports scheduling mechanism configurations.
Restrictions
None.
