● Remove the transmission bleeder tube.
● Remove the RH./LH. radiator hose from the RH.
crankcase.
● Face the LH. crankcase downward, and remove the
RH. crankcase from the LH. crankcase while tapping a
few places on the LH. crankcase with a plastic hammer.
CRANKSHAFT REMOVAL
● Remove the crankshaft from the RH. crankcase by
using a crankshaft remover.
● If the bearing is left on the RH. crankcase, use the
driver handle and the outer driver to remove it.
TOOLS : DRIVER
ATTACHMENT, 42 X 47 mm
● If the bearing is left on the crankshaft, use a bearing
puller to remove it.
TOOL : UNIVERSAL BEARING PULLER
● Remove the dowel pin and gasket.
·Be careful not to distort the mating surface of the
crank case during removal.
·After removing the crankshaft from the RH.
crankcase, replace the RH. crankshaft bearing with a
new one.
