- 93 -
Maintenance Section
Wheel Bolts and Nuts - Inspect
Inspect Tightness
NOTICE
Do not lubricate ball seas of wheels or ball
faces of wheel nuts.
Be sure mounting faces of hub, wheel nuts and
flat mounting surfaces are clean.
Tighten wheel nuts again after 24 hours of
operation.
NOTE : Always tighten wheel lug nuts in a
sequence opposite (180¡) each other.
If equipped with dual wheels, follow the same nut
tightening sequence for both wheels.
Steer Wheels
Install steer wheel. Put two nuts opposite (180¡)
each other. Tighten both.
Install remaining nuts. Tighten all nuts in a
sequence opposite (180¡) each other. Tighten to
440
L
35 N
•
m (325
L
25 lb
•
ft).
Drive Wheels
Install drive wheel. Put two nuts opposite (180¡)
each other. Tighten both.
Install the remaining nuts. Tighten all nuts in a
sequence opposite (180¡) each other. Tighten to
600
L
90 N
•
m (440
L
60 lb
•
ft).
IA3M4014
IAOM4015
