Daewoo DE12T - Standard Bolt Tightening Torque Table; Degree of Strength

•
Standard bolt tightening torque table
Refer to the following table for bolts other then described above
Others : 1.The above torque rating have been determined to 70% or so of the limit value for bolt elas-
ticity.
2. Tension is calculated by multiplying tensile strength by cross section of thread.
3. Special screws should be tightened to 85% or so of the standard value.
For example, a screw coated with MoS2 should be tightened to 60% or so of the stan-
dard value.
•
Tightening torque for hollow screw (4-hole)
* : Adopted in DAEWOO engine
- 177 -
APPENDIX
Degree of strength
Diameter 3.6 4.6 4.8 5.6 5.8 6.6 6.8 6.9 8.8 10.9 12.9
B
(4A) (4D) (4S) (5D) (5S) (6D) (6S) (6G) (8G) (10K) (12K)
pitch Limit value for elasticity (kg/mm
2
)
(mm) 20 24 32 30 40 36 48 54 64 90 108
Tightening torque (kg
•
m)
M5 0.15 0.16 0.25 0.22 0.31 0.28 0.43 0.48 0.5 0.75 0.9
M6 0.28 0.30 0.45 0.4 0.55 0.47 0.77 0.85 0.9 1.25 0.5
M7 0.43 0.46 0.7 0.63 0.83 0.78 1.2 1.3 1.4 1.95 2.35
M8 0.7 0.75 1.1 1 1.4 1.25 1.9 2.1 2.2 3.1 3.8
M8
B
1 0.73 0.8 1.2 1.1 1.5 1.34 2.1 2.3 2.4 3.35 4.1
M10 1.35 1.4 2.2 1.9 2.7 2.35 3.7 4.2 4.4 6.2 7.4
M10
B
1 1.5 1.6 2.5 2.1 3.1 2.8 4.3 4.9 5 7 8.4
M12 2.4 2.5 3.7 3.3 4.7 4.2 6.3 7.2 7.5 10.5 12.5
M12
B
1.5 2.55 2.7 4 3.5 5 4.6 6.8 7.7 8 11.2 13.4
M14 3.7 3.9 6 5.2 7.5 7 10 11.5 12 17 20
M14
B
1.5 4.1 4.3 6.6 5.7 8.3 7.5 11.1 12.5 13 18.5 22
M16 5.6 6 9 8 11.5 10.5 17.9 18.5 18 26 31
M16
B
1.5 6.2 6.5 9.7 8.6 12.5 11.3 17 19.5 20 28 33
M18 7.8 8.3 12.5 11 16 14.5 21 24.2 25 36 43
M18
B
1.5 9.1 9.5 14.5 12.5 18.5 16.7 24.5 27.5 28 41 49
M20 11.5 12 18 16 22 19 31.5 35 36 51 60
M20
B
1.5 12.8 13.5 20.5 18 25 22.5 35 39.5 41 58 68
M22 15.5 16 24.5 21 30 26 42 46 49 67 75
M22
B
1.5 17 18.5 28 24 34 29 47 52 56 75 85
M24 20.5 21.5 33 27 40 34 55 58 63 82 92
M24
B
1.5 23 25 37 31 45 38 61 67 74 93 103
Material M8 M10 M12 M14 M16 M18 M22 M26 M30 M38
SM25C - 1.6 2.5 3.5 4.5 5.5 9.0 13.0 18.0 30.0
*SUM22L 0.8 1.8 3.0 4.0 5.5 6.5 11.0 16.0 20.0 35.0
STS304 0.8 1.8 3.0 4.0 5.5 6.5 11.0 16.0 20.0 35.0
