- 87 -
REASSEMBLY
•
Apply engine oil to an expander and
install it onto the special tool (guider).
•
Tighten the bolts until the expander is
forced out of the cylinder head bottom.
•
After mounting the nozzle tube, make
a hydraulic test to check for water
leaks.
3.3.22. Rocker arm assembly
•
Apply lubricating oil to the rocker arm
bush and shaft, and assemble the
intermediate bracket with the rocker
arm using fixing bolts.
•
Semi-install valve clearance adjusting
bolts onto the rocker arm.
•
Install the spring, rocker arm, bracket,
rocker arm, spring, washer, and snap
ring in the described sequence.
•
Install the rocker arm and bracket in
the same direction.
Test pressure 2 kg/cm
2
Torque 4.4 kg
.
m
