Apply oil to the entire part of the bear-
ing cap bolts, then tighten in tighten-
ing sequence to specified torque.
•
After semi-tightening both bolts even-
ly, tighten them diagonally to about
15kg
.
m for the first stage and 25 kg
.
m
for the second stage respectively,
then tighten them completely to the
specified torque using a torque
wrench.
•
Tighten the bearing cap in the
sequence of 4-3-5-2-6-1-7.
•
Check to see that the assembled
crankshaft turns smoothly.
3.3.6.
Flywheel housing
•
Temporarily install the guide bar on
the cylinder block.
•
Apply gasket to the cylinder block.
•
Using the dowel pin and guide bar,
install the flywheel housing and tight-
en the fixing bolts in a diagonal
sequence to specified torque.
3.3.7.
Rear oil seal
•
Apply lubricating oil to the outside of
the oil seal and flywheel housing
inside diameter and fit them over the
crank shaft, then assemble the oil seal
using an oil seal fitting jig.
- 79 -
REASSEMBLY
