DAF LF45 Series - Page 165

1
LF45/55 series General
CAB TILTING GEAR
2-3
2.3 OVERVIEW DRAWING, LIFTING CYLINDER
Legend
1. Split pin
2. Dowel pin
3. Lifting cylinder
4. Washer
5. Bottom attachment nut
6. Hydraulic lines
K1 01 220
1
2
4
5
6
3
K1 01 222
6
