LF45/55 series Removal and installation
SEATS
4-27
4.31 REMOVAL AND INSTALLAT ION, GAS SPRING OF GAS-SPRUNG SEAT
Removing gas spring of gas-sprung seat
1. Remove the seat squab.
2. Remove the nut (1).
3. Remove the circlip (2).
4. Remove the gas spring (3).
Installing gas spring of gas-sprung seat
1. Fit the gas spring (3).
2. Fit the circlip (2).
3. Fit the nut (1).
4. Fit the seat squab.
1
2
3
K1 01 406
7
ǹ 0210
